Mattei BLADE 15 Series User Manual

BLADE
3-7
TI215G0010
TECHNICAL DATA AND OVERALL DIMENSIONS
POSITION OF MAIN PARTS
1 Compressor
2 Air filter
3 Oil separator filter
4 Oil filter
5 Air / oil separator
6 Manometer
7 Electric motor
8 Air / oil radiator
9 Electric starter
10 Oil filler plug
11 Oil drain cock
12 Intake pre-filter
13 Water IN / OUT connections for the heat recovery
14 Condensate drain connection for the dryer
(*)
15 Maestro
XB
16 Dryer
(*)
17 Electronic drain
(*)
18 Air delivery
19 Electricity supply
20 Air deliver
(*)
21 Inverter
(**)
22 Electric fan
(*) Plus version
(**) “i” version
Description of the machine
158
9
2
14
13
16
20
18
17
12
6
5
10 1
21
7
11
19
3
4
22
