Fife-200 Web Guiding System
MI 1-918 1 C
Mounting dimensions
Refer to Figure 1 for references to dimensions for the Actuator Mounting, Inside Type.
Roll Face
and
Guide Span
A
Roll
Diameter
B
D
Maximum
Correction
J
Maximum
Tension
T
Correction
Speed
S
Height
H
C
Guide
Center
Distance
GGG
60
[2.362]
25 [0.984]
30
[1.181]
+/-10
[+/-0.394]
49 N
[11 lb]
61 mm/s
[2.402 in/s]
78.5
[3.091]
56
[2.205]
125 to 350
[4.921 to
13.780]
110
[4.331]
25 [0.984]
48.5
[1.909]
+/-12
[+/-0.472]
67 mm/s
[2.638 in/s]
98.5
[3.878]
77.5
[3.051]
160 to 350
[6.299 to
13.780]
50 [1.969]
140
[5.512]
25 [0.984]
61.5
[2.421]
76 mm/s
[2.992 in/s]
103.5
[4.075]
85
[3.346]
175 to 350
[6.890 to
13.780]
50 [1.969]
200
[7.874]
25 [0.984]
100
[3.937]
81 mm/s
[3.189 in/s]
103.5
[4.075]
113.5
[4.469]
205 to 350
[8.071 to
13.780]
50 [1.969]
Table 1. Dimensions for actuator mounting inside.
Refer to Figure 2 for references to dimensions for the Actuator Mounting, Outside Type.
Roll Face
and
Guide Span
A
Roll
Diameter
B
D
Maximum
Correction
J
Maximum
Tension
T
Correction
Speed
S
Height
H
C
Guide
Center
Distance
GGG
60
[2.362]
25 [0.984]
30
[1.181]
+/-10
[+/-0.394]
49 N
[11 lb]
61 mm/s
[2.402 in/s]
78.5
[3.091]
134
[5.276]
125 to 300
[4.921 to
11.811]
110
[4.331]
25 [0.984]
48.5
[1.909]
+/-12
[+/-0.472]
67 mm/s
[2.638 in/s]
98.5
[3.878]
155.5
[6.122]
125 to 300
[4.921 to
11.811]
50 [1.969]
140
[5.512]
25 [0.984]
61.5
[2.421]
76 mm/s
[2.992 in/s]
103.5
[4.075]
163
[6.417]
125 to 300
[4.921 to
11.811]
50 [1.969]
200
[7.874]
25 [0.984]
100
[3.937]
81 mm/s
[3.189 in/s]
103.5
[4.075]
191.5
[7.539]
135 to 300
[5.315 to
11.811]
50 [1.969]
Table 2. Dimensions for actuator mounting outside.
