6–2
SPECIFICATIONS
www.maxcessintl.com
Fife-200 Web Guiding System
MI 1-918 1 C
Controller specifications
Input voltage range
-
22.5 to 26.4 VDC
Proper earth grounding is required.
Note that the negative supply and housing
ground are interconnected.
The power supply must have an SELV output,
such as Puls CS10.241-S1, or equivalent.
Supply current
-
5 A maximum
Internal fuse
-
10 A, slow-blow
Dimensions
Controller
-
Height – 62 mm [2.44 in]
Width – 147 mm [5.79 in]
Length – 260 mm [10.24 in]
Product certifications
-
CE
TUV Rheinland of North America
to UL61010-1
and
CAN/CSA-C22.2 No. 61010-1 and
CB Certificate to IEC61010-1
Inputs and outputs
Number of guides controlled
-
Four (two when using SE-26A)
Sensor input (four)
-
One per guide
Max input +/-20 mA
Individually programmable
0 to 10 mA (preferred)
Digital port
-
12 digital inputs, three per guide
Active high
Low level: 0 to 0.9 V
High level 3.5 to 24 V
Four outputs, one per guide
Open collector
55 mA at 1.6V saturation
Maximum +30 VDC applied to output
+12 V available to port for input reference
Supply to accessories
-
+12 V +/-5%, 600 mA maximum
-12 V +/-5%, 80 mA maximum
