INSTALLATION 3 - 4
DSE-17www.maxcess.eu MI 1064 1 C
Montage.fm
1 Square bar
Figure 3.3: DSE-17-300/-420 with sensor bracket of type MB
X
C B
A
1
X
BC
A
1
1 Square bar
Figure 3.4: DSE-17-160 with sensor bracket of type MB
Mechanical
fastening
Square bar
ABC
X
Max. length
DSE-17-160 DSE-17-300 DSE-17-420
MB-20 20 1450 1400 1350 70,5 ca. 43 15
MB-25 25 1800 1750 1700 73,5 ca. 47 19
MB-32 32 2350 2300 2250 78,5 ca. 52 24
