10
Rear Panel Connections
Composite / S-Video Inputs
Connect Composite or S-Video signals from
external sources such VCRs or DVD players.
Component Video Inputs
Auto-detecting component video inputs (Y/Pb/Pr or
Y/Cb/Cr) for connecting to the component output
jacks of a DVD player or Set-Top Box.
Audio Output
Variable or fixed audio output jacks for connecting
to an external audio amplifier.
Subwoofer Output
Variable or fixed low-frequency audio output jack for
connecting to an external amplified subwoofer.
Digital DVI Inputs
Connects to the digital video signals
from a set top box or PC. An optional 2-port DVI
module is available.
RGB Input
Connect to RGB output of computer or Set-Top box.
RGB Output
Connect to another computer monitor for daisy
chaining applications.
RS-232 Connector
Connect to a computer serial port.
Getting to Know Your Display
-
