Maxim Integrated MAX32664 - Page 24

Maxim Integrated Page 24 of 52
HOST COMMAND
MAX32664
FAMILY NAME
DESCRIPTION
FAMILY
BYTE
INDEX
BYTE
WRITE BYTES
RESPONSE BYTES
Dump Registers
Read all the
MAX30101 registers.
(MAX32664GWEA,
MAX32664GWED)
0x43
0x03
-
Register address 0, register value 0,
register address 1, register value 1, …,
register address n, register value n
Dump Registers
Read all the
accelerometer sensor
registers.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC,
MAX32664GWED)
0x43
0x04
-
Register address 0, register value 0,
register address 1, register value 1, …,
register address n, register value n
Sensor Mode
Enable
Enable the
MAX86140/
MAX86141 sensor.
(MAX32664GWEB,
MAX32664GWEC)
0x44
0x00
0x00: Disable
0x01: Enable
-
Sensor Mode
Enable
Enable the
MAX30205 sensor.
(MAX32664GWEB)
0x44
0x01
0x00: Disable
0x01: Enable
-
Sensor Mode
Enable
Enable the
MAX30001 sensor.
(MAX32664GWEB)
0x44
0x02
0x00: Disable
0x01: Enable
-
Sensor Mode
Enable
Enable the
MAX30101 sensor.
(MAX32664GWEA,
(MAX32664GWED)
0x44
0x03
0x00: Disable
0x01: Enable
-
Sensor Mode
Enable
Enable the external
accelerometer
sensor. This
command is used
when host
accelerometer data
is supplied to the
sensor
hub.(MAX32664GWE
A, MAX32664GWEB,
MAX32664GWEC)
0x44
0x04
0x00: Disable, 0x00: Sensor
Hub accelerometer
0x00: Disable, 0x01: External
Host accelerometer
0x01: Enable, 0x00: Sensor
Hub accelerometer
0x01: Enable, 0x01: External
Host accelerometer
-
Sensor Mode
Read
Read the MAX86140/
MAX86141 sensor
mode.
(MAX32664GWEB,
MAX32664GWEC)
0x45
0x00
0x00: Disabled
0x01: Enabled
Sensor Mode
Read
Read the MAX30205
sensor mode.
(MAX32664GWEB)
0x45
0x01
0x00: Disabled
0x01: Enabled
Sensor Mode
Read
Read the MAX30001
sensor mode.
(MAX32664GWEB)
0x45
0x02
0x00: Disabled
0x01: Enabled
Sensor Mode
Read
Read the MAX30101
sensor mode.
(MAX32664GWEA,
(MAX32664GWED)
0x45
0x03
0x00: Disabled
0x01: Enabled
