HOST COMMAND
MAX32664
FAMILY NAME
DESCRIPTION
FAMILY
BYTE
INDEX
BYTE
WRITE BYTES
RESPONSE BYTES
Sensor Mode
Read
Read the external
accelerometer
sensor mode.
(MAX32664GWEA,
MAX32664GWEB,
MAX32664GWEC)
0x45
0x04
0x00: Disabled, 0x00: Sensor Hub
accelerometer
0x00: Disabled, 0x01: External Host
accelerometer
0x01: Enabled, 0x00: Sensor Hub
accelerometer
0x01: Enabled, 0x01: External Host
accelerometer
Algorithm
Configuration
Automatic Gain
Control (AGC)
algorithm: Set the
target percentage of
the full-scale ADC
range that the
automatic gain
control (AGC)
algorithm uses.
(MAX32664GWEA,
MAX32664GWED)
0x50
0x00
0x00, 0 to 100 percent
-
Algorithm
Configuration
AGC algorithm: Set
the step size toward
the target for the AGC
algorithm.
(MAX32664GWEA,
MAX32664GWED)
0x50
0x00
0x01, 0 to 100 percent
-
Algorithm
Configuration
AGC algorithm: Set
the sensitivity for the
AGC algorithm.
(MAX32664GWEA,
MAX32664GWED)
0x50
0x00
0x02,. 0 to 100 percent
-
Algorithm
Configuration
AGC algorithm: Set
the number of
samples to average
for the AGC
algorithm.
(MAX32664GWEA)
0x50
0x00
0x03, Number of samples to
average (range is 0 to 255).
-
Algorithm
Configuration
Wrist Heart Rate
Monitor (WHRM)
algorithm: Set the
sample rate for the
WHRM algorithm.
The WHRM algorithm
is configured to use
the LED1 and Photo-
diode 1 (25Hz sample
rate) and is
compatible with the
MAX86141 AFE, KX-
122 accelerometer.
(MAX32664GWEB)
0x50
0x02
0x00, MSB of sample rate,
LSB of sample rate
(16-bit unsigned integer)
-
