maximo PV2024 HM - Page 27

27
Charging algorithm for
Lithium battery
Joint AC and Solar Charging
INVERTER MODEL
2024/3024
Max Charging Current
70Amp
80Amp
Default Charging Current
40Amp
60Amp
Table 4 General Specifications
INVERTER MODEL
2024
3024
Safety Certification
CE
Back-feed current to array
0 Amp
0 Amp
Inrush current
30 Amp
30 Amp
Max output fault current
10.4 Amp
15.7 Amp
Max output overcurrent
protection
7.7 Amp
11.5 Amp
Operating Temperature Range
0°C to 55°C
Storage temperature
-15°C~ 60°C
Dimension (D*W*H), mm
272x 355 x 125
Net Weight, kg
10.5
11.5
