Motherboard Design Guide
maxon motor control
EPOS4 Positioning Controller Document ID: rel8003
4-71
EPOS4 Module/Compact 50/5 Hardware Reference Edition: May 2018
© 2018 maxon motor. Subject to change without prior notice.
4 Motherboard Design Guide
The «Motherboard Design Guide» provides helpful information on integrating the Module on a printed
circuit board. It contains recommendations for the motherboard layout and specifies external compo-
nents that may be required, pin assignments, and connection examples.
Get help
If you are not trained in the design and development of printed circuit boards, you will need additional
support for this point.
maxon motor will be happy to provide you with a quote for designing and manufacturing a motherboard
for your specific application.
CAUTION
Dangerous Action
Errors in implementing the design can result in serious Injury!
• Only proceed if you are skilled in electronics design!
• Designing a printed circuit board requires special skills and knowledge and may only be performed
by experienced electronic developers!
• This quick guide is only intended as an aid, does not make any claim to completeness, and will not
automatically result in a functional component!
