4.1.6 Recommended Components and Manufacturers
Table 4-65 Motherboard Design Guide – Recommended components
Recommended components
Socket
header
Dual row socket strip, pluggable, 1.27 mm pitch, contact length 2.9 mm, current rating per pin = I
cont
/ 1 A
23 poles, 2 rows:
• maxon motor (590738)
• E-Tec (BS2-046-H45B-55/11)
• Confectronic / Elcotron (2243-A46G00DPT-M/U842)
Fuse
(FU1)
• Littelfuse 157 Series, Fuse 10 A, 26.46 A
2
sec (0157010)
TVS Diode
(D1; D2)
• Vishay (SMBJ54A) U
R
= 54 V, U
BR
= 60.0…66.3 V @ 1 mA, U
C
= 87.1 V @ 6.9 A
• Fairchild (SMBJ54A) U
R
= 54 V, U
BR
= 60.0…66.6 V @ 1 mA, U
C
= 87.1 V @ 6.9 A
• Littelfuse (SMBJ54A) U
R
= 54 V, U
BR
= 60.0…66.6 V @ 1 mA, U
C
= 87.1 V @ 6.9 A
Capacitor
(C1)
The ripple current load for C1 depends on the motor’s operating point and the power supply output capacity.
Under worst case conditions however, the ripple current may reach I
cont
/ 2. Use capacitors with rated
voltage ≥63 V and adequate ripple current to avoid overheat or life time reduction.
Example for C1 worst-case dimensioning:
I
cont
= 5 A  Rubycon (63YXJ470M12.5X25); 470 μF, 63 V, 1990 mA r.m.s.
Capacitor
(C2)
To avoid voltage overshoot at power plug-in with a separately sourced logic supply, use an electrolytic
capacitor covering the following requirements: 33 μF or 47 μF, 63 V, at least 265 mA r.m.s.
• Rubicon (63ZLH47MEFCTA6.3X11) or (63YXJ47M6.3X11)
• Panasonic (EEU-FR1J470B)
• Nippon Chemicon (EKYB630ELL330MF11D) or (EKY-630 ELL330MF11D)
Motor Choke
(L)
Inductance: “Motor Cables and Motor Chokes” on page 4-74
Rated current: I
rms
≥ I
cont
; I
sat
≥ I
peak
Construction: shielded
10 μH:
• Würth (WE-PD-XXL / 7447709100) I
rms
7.1 A, I
sat
10.5 A, 12 x 12 x 10 mm
2.2 μH:
• Bourns (SRP7028A-2R2M) I
rms
8 A, I
sat
14 A, 7.3 x 6.6 x 2.8 mm
• Eaton (HCM0703-2R2-R) I
rms
8 A, I
sat
14 A, 7.1 x 6.6 x 3 mm
• Würth (744311220) I
rms
9 A, I
sat
13 A, 7 x 6.9 x 3.8 mm
Motor Filter
Example 1
• Motor Choke L 10 μH
• Filter Capacitor Cf 220 pF, 100 V
• Snubber Capacitor Cs 470 pF, 100 V
• Snubber Resistor Rs 220 Ω, 0.25 W
Example 2
• Motor Choke L 2.2 μH
• Filter Capacitor Cf 220 pF, 100 V
• Snubber Capacitor Cs 470 pF, 100 V
• Snubber Resistor Rs 100 Ω, 0.25 W
RS232
(IC1)
(C3…C7)
RS232 transceiver (IC1)
• Texas Instruments (MAX202IPW)
• ST Microelectronics (ST202EBTR)
Capacitors (C3…C7)
• 100 nF, X7R, 16 V
