Maxon BMR-55 - Opening the Retention Ramp

15
OPENING THE RETENTION RAMP
To unfold retention ramp, pull
lock in direction of arrow (FIG.
15-1) and rotate ramp to the
ground (FIG. 15-2).
RAMP
POSITION
LOCK
(PULL TO RELEASE)
FIG. 15-1
FIG. 15-2
RAMP
STOWED
POSITION
