Maxon DMD series - Moving Retention Ramp to Position

11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
27
5. Remove LH torsion bar pin (FIGS. 27-1 and
27-1A).
FIG. 27-1
TORSION
BAR PIN
6. Loosen locking screw on LH torsion
bar housing (FIGS. 27-2 and 27-2A).
FIG. 27-2
FIG. 27-2A
LOCKING
SCREW
LH HOUSING
REMOVING LH TORSION BAR PIN
FIG. 27-1A
RH TORSION
BAR PIN (REF)
