Installation and Operating Instruction
Connect to AC
Make sure that the voltage and frequency are correct. Plug the UPS into a 2
pole,3 wire grounding receptacle(wall outlet).Make sure the wall outlet branch
is protected. Avoid using extension cords at all possible. if used, make sure
the extension cord is rated for 15 Amps.
For 220/230/240V versions: swap the input power cord of the equipment to the
inlet of UPS. Use the power cord supplied with the UPS to connect from the
outlet of the UPS to your equipment.
Determining the Load:
1. Make a list of all equipment that requires protection.
2.Calculate the sum of all the V x A ratings.(Input voltage/current shown on
name plate).
3.Ensure that the total VA rating does not exceed the rated capacity of the
UPS.
If rated unit capacities are exceeded, an overload condition may occur and
cause the UPS unit to shut down or the circuit breaker to trip.
Do not plug a laser printer or copy machine into the outlets of this UPS.
The power demands of these particular devices are much higher than typical
peripherals.
Connect the Load
Plug your primary equipment(e.g: computer, monitor, critical data storage
device, etc.)into the Battery Power Protected outlets. Leave the power
switches of the equipment in the “Off” position for the moment.
Connect to Computer
Use the enclosed RS-232 (DB9)cable. Plug the 8-pin colorless male end into the UPS.
Plug the 9-pin female end into an open COM port on the computer (9-pin
Male).
Connect the Fax Lines
To protect a fax connect the telephone cable from the wall outlet to the “IN” jack of the
UPS. Connect the telephone cable from the “OUT “phone outlet on the UPS to the fax.
The phone jacks on the UPS accept standard sized phone cables ( RJ11
communication cables ).
Please check with your local dealer for the monitoring software.
