9XTend‐PKG‐R™RS‐232/485RFModem–ProductManualv1.2.4
©2005MaxStream,Inc.ConfidentialandProprietary 23
4.3. Command Reference
Table4‐03. XTendCommandsasoffirmwarev1.2.4(“d”denotesdecimalequivalent)
AT
Command
Binary
Command
AT Command Name Parameter Range
Command
Category
# Bytes
Returned
Factory
Default
%V 0x3B (59d) Board Voltage 0x2CCCA – 0x5BFFA [read-only] Diagnostics 4 -
AM 0x40 (64d) Auto-set MY - Networking & Security - -
AT 0x05 (5d) Guard Time After 2 - (ATST-3) [x 100 msec] Command Mode Options 2 0x0A (10d)
BD 0x15 (21d) Baud Rate (Serial Data Rate) 0 - 8 Serial Interfacing 1 3
BR 0x39 (57d) RF Data Rate 0 - 1 RF Interfacing 1 1
BT 0x04 (4d) Guard Time Before 0 – 0xFFFF [x 100 msec] Command Mode Options 2 0x0A (10d)
CC 0x13 (19d) Command Sequence Character 0x20 - 0x7F Command Mode Options 1 0x2B [“+”] (43d)
CD 0x28 (40d) GPO2 Configuration 0 - 2 Serial Interfacing 1 2
CF - Number Base 0 - 2 Command Mode Options 1 1
CN 0x09 (9d) Exit Command Mode - Command Mode Options - -
CS 0x1F (31d) GPO1 Configuration 0 - 4 Serial Interfacing 1 0
CT 0x06 (6d) Command Mode Timeout 2 – 0xFFFF [x 100 ms] Command Mode Options 2 0xC8 (200d)
DB 0x36 (54d) Received Signal Strength 0x6E to 0x28 [read-only] Diagnostics 2 -
DT 0x00 (0d) Destination Address 0 - 0xFFFF Networking & Security 2 0
E0 0x0A (10d) Echo Off - Command Mode Options - -
E1 0x0B (11d) Echo On - Command Mode Options - -
ER 0x0F (15d) Receive Error Count 0 – 0xFFFF Diagnostics 2 0
FH 0x0D (13d) Force Wake-up Initializer - Sleep (Low Power) - -
FL 0x07 (7d) Software Flow Control 0 - 1 Serial Interfacing 1 0
FS 0x3E (62d) Forced Sync Time 1 – 0xFFFF [x 10 msec] RF Interfacing 2 0
FT 0x24 (36d) Flow Control Threshold 0 – DI Buffer size (bytes) Serial Interfacing 2 varies
GD 0x10 (16d) Receive Good Count 0 – 0xFFFF Diagnostics 2 0
HP 0x11 (17d) Hopping Channel 0 - 9 Networking & Security 1 0
HT 0x03 (3d) Time before Wake-up Initializer 0 – 0xFFFF [x 100 msec] Sleep (Low Power) 2 0xFFFF (65535d)
HV - Hardware Version 0 – 0xFFFF [read-only] Diagnostics 2 -
ID 0x27 (39d) Modem VID
0 - 0x7FFF (user-settable)
0x8000 - 0xFFFF (factory-set)
Networking & Security 2 0x3332 (13106d)
KY 0x3C (60d) AES Encryption Key 0 – (Any other 64-digit hex valid key) Networking & Security 2 0
LH 0x0C (12d) Wake-up Initializer Timer 0 – 0xFF [x 100 msec] Sleep (Low Power) 1 1
MK 0x12 (18d) Address Mask 0 - 0xFFFF Networking & Security 2 0xFFFF (65535d)
MT 0x3D (61d) Multi-Transmit 0 – 0xFF Networking & Security 1 0
MY 0x2A (42d) Source Address 0 - 0xFFFF Networking & Security 2 0xFFFF (65535d)
NB 0x23 (35d) Parity 0 - 4 Serial Interfacing 1 0
PK 0x29 (41d) Maximum RF Packet Size 1 – 0x800 [Bytes] RF Interfacing 2 0x800 (2048d)
PL 0x3A (58d) TX Power Level 0 - 4 RF Interfacing 1 4 [1 Watt]
PW 0x1D (29d) Pin Wake-up 0 - 1 Sleep (Low Power) 1 0
RB 0x20 (32d) Packetization Threshold 1 - Current value of PK Serial Interfacing 2 0x800 (2048d)
RC - Ambient Power - Single Channel 0 – 0x31 [dBm, read-only] Diagnostics 1 -
RE 0x0E (14d) Restore Defaults - (Special) - -
RM - Ambient Power - All Channels No parameter – 0x7D0 Diagnostics 2 -
RN 0x19 (25d) Delay Slots 0 – 0xFF (slots) Networking & Security 1 0
RO 0x21 (33d) Packetization Timeout 0 – 0xFFFF [x UART character time] Serial Interfacing 2 3
RP 0x22 (34d) RSSI PWM Timer 0 – 0xFF [x 100 msec] Diagnostics 1 0x20 (32d)
RR 0x18 (24d) Retries 0 – 0xFF Networking & Security 1 0x0A (10d)
RT 0x16 (22d) GPI1 Configuration 0 - 2 Serial Interfacing 1 0
SB 0x37 (55d) Stop Bits 0 - 1 Serial Interfacing 1 0
SH 0x25 (37d) Serial Number High 0 – 0xFFFF [read-only] Diagnostics 2 varies
SL 0x26 (38d) Serial Number Low 0 – 0xFFFF [read-only] Diagnostics 2 varies
SM 0x01 (1d) Sleep Mode 0 - 2, 4 - 8; 3 reserved Sleep (Low Power) 1 0
ST 0x02 (2d) Time before Sleep (ATAT+3) – 0x7FFF [x 100 msec] Sleep (Low Power) 2 0x64 (100d)
TP 0x38 (56d) Board Temperature 0 – 0x7F [read-only] Diagnostics 1 -
TR 0x1B (27d) Delivery Failure Count 0 – 0xFFFF [read-only] Diagnostics 2 0
TT 0x1A (26d) Streaming Limit 0 – 0xFFFF [0 = disabled] Networking & Security 2 0
TX 0x3F (63d) Transmit Only 0 - 1 RF Interfacing 1 0
VL - Firmware Version - verbose Returns string Diagnostics - -
VR 0x14 (20d) Firmware Version 0 - 0xFFFF [read-only] Diagnostics 2 -
WA - Active Warning Numbers Returns string Diagnostics - -
WN - Warning Data Returns string Diagnostics - -
WR 0x08 (8d) Write - (Special) - -
WS - Sticky Warning Numbers Returns string Diagnostics - -
