Chapter 2: Locations
Exterior Views
Hull Views
TRANSOM
STERN EYESTERN EYE
GARBOARD
DRAIN PLUG
STARBOARD HULLSIDE
PORT HULLSIDE
BILGE PUMP
DRAIN
BOW EYE
TRANSOM
BOW EYE
DECK DRAIN
DECK DRAIN
STORAGE DRAIN
DECK DRAIN
TRANSOM
STORAGE DRAIN
TRIM TAB
(IF EQUIPPED)
TRIM TAB
(IF EQUIPPED)
PORTABLE HEAD
VENT (IF EQUIPPED)
PORTABLE HEAD WASTE
PUMP-OUT THRU-HULL
FITTING (IF EQUIPPED)
