Maxum 2400 SR3 - Component Locations

Chapter 2: Locations
13
Component Locations
12-Volt Accessory Outlet: Located at the
helm on the starboard switch panel.
Battery: Located on the port
side of the engine compartment.
Battery Switch (If Equipped):
Located on the port side of the
engine compartment.
Bilge Pump: Located in the engine
compartment, forward of the engine.
12-VOLT
RECEPTACLE
BATTERY
BATTERY SWITCH
(IF EQUIPPED)
BILGE PUMP
ENGINE
