Hull Electrical Harness
BATTERY
ENGINE
FUEL TANK
BILGE PUMP
ENGINE
GROUND
ENGINE
BLOWER
NOTES:
POSITIVE BATTERY CABLES ARE RED
NEGATIVE BATTERY CABLES ARE YELLOW
