Chapter 2: Locations
16
Freshwater Tank ‘Drain Hose & Plug’: Located
at the aft end of the freshwater tank.
Fuel Fill/Vent Deck Fitting: Located on the
starboard side of the aft deck.
Fuel Filter: Located in the
engine compartment, for-
ward of the engine.
Fuel Tank: Located under
the floor just forward of the
engine compartment.
FRESHWATER
TANK
DRAIN PLUG
DRAIN HOSE
WATER PUMP
WATER FILTER
FUEL FILL/VENT
DECK FITTING
FUEL FILTER
FUEL TANK
