Maxum 2400 SR3 - L-lounge to Sunlounge Conversion (If Equipped)

Chapter 8: Convertible Seats, Beds, & Tables
43
L-lounge to Sunlounge Conversion (If Equipped)
1. Place the support post (A) into the base (B) in
the floor.
2. Extend the folding legs (C) on the filler board (D) and
place the filler board on top of the support post (A).
3. Place the filler cushion (E) on top of the filler board,
and snap the cushion hold down straps (not pictured)
to the receiving snaps on the filler board.
A
B
A
C
D
E
