Maxum 4600 SCB - DC Engine Harness; Battery Ground Cable Routing

Chapter 3: Electrical Routings 33
4600 SCB Owner’s Manual Supplement
DC Engine Harness
Battery Ground Cable Routing
TO PORT
ENGINE PLUG
TO STARBOARD ENGINE PLUG
COMMAND BRIDGE PLUG
TO COMMAND BRIDGE HELM
NEGATIVE BUSS
TO BATTERY
SWITCH
LOWER HELM
PLUG (OPTION)
TO DC PANEL
INVERTER
TO PORT
ENGINE
GROUND
TO STARBOARD
ENGINE GROUND
INVERTER (OPTION)
PORT ENGINE BATTERY
SWITCH
TO BUSS BAR
BATTERY
(OPTION)
INVERTER
(OPTION)
TO STARBOARD
ENGINE BATTERY
