RC12 Windlass
Installation
General Requirements
Foredeck layout
Make sure that the area of deck between the windlass and the bow roller is clear of obstructions.
The bow roller should have a central groove suitable for the chain size.
Use a chain guide if necessary to prevent the chain from running against the deckplate and
potentially causing damage to the windlass.
Provide a chain stopper, snubber or cleat to secure the anchor line when under way. Tie the
anchor line to a bollard or cleat when at anchor.
Anchor and rope/chain considerations
When purchasing an anchor, make sure it fits into the bow roller and is self-launching.
Use a swivel between the anchor and the chain to prevent the line from twisting as the anchor is
raised or lowered.
To prevent build up of rope/chain on deck causing possible damage, the bow roller must allow the
anchor to free fall immediately when the anchor is deployed.
Make sure that at least three links of chain are exposed when the anchor is docked.
The rope/chain must gravity feed into the locker.
NOTE
: Make sure you securely fasten the end of the rope/chain to the boat.
Required clearances
Ideally the outlet for the rope/chain should be directly over the rope/chain locker. The rope/chain
should have at least 200mm (8”) clear fall from bottom of motor to rope/chain pile to allow the
rope/chain to straighten before passing through the windlass.
Position the windlass clear of pulpit, lifelines and bulwark so that there is room to swing the Clutch
Handle.
The rope/chain locker must be of such a size that the rope/chain will heap up and feed out
naturally without fouling the windlass motor.
Allow access for conveniently connecting the supply lines under deck after the windlass is bolted
in position.
It should be noted that the gearbox can be indexed at different positions in relation to the deck
plate. Be sure to select the most convenient position and allow for the best run for the rope/chain
to clear the motor.
Aligning the windlass
“UP” is the clockwise rotation when looking down on the windlass.
The windlass must be positioned to allow the rope/chain to have a clear run from the bow roller to
the chainwheel.
The deck plate should be mounted pointing in the direction of the incoming rope/chain. This
arrangement allows the rope/chain to have maximum engagement with the chainwheel.
The bow roller should have a vertical groove to suit the profile of the chain. This will align the
chain so that it enters the chainwheel without twisting.
