Maxwell RC12 - Windlass Parts List

RC12 Windlass
Windlass parts
Item
Component description
Qty
Part No.
1
Cap
1
7191
2
O-ring
1
SP2790
3
Screw M8 x 25
1
SP0095
4
Retaining Washer
1
3267
5
Clutch Nut
1
7440
Clutch Nut Capstan
1
7441
6
Washer - Capstan only
1
7527
7
Capstan
1
7443
8
Clutch Cone
2
7439
9
Bellville Washer
2
5015
10
Cap screw -M5 x 16
3
SP0178
11
Chainwheel -upper -10mm- 3/8" CW
1
7448
Chainwheel -upper -12mm-1/2" CW
1
7452
Chainwheel -lower -10mm- 3/8" ACW
1
7448
Chainwheel -lower -12mm-1/2" ACW
1
7452
12
Bush
1
7544
13
Cap screw -M6 x 70
2
SP4509
14
Spring washer
2
SP0474
15
Stripper
1
7444
16
Chainwheel -lower-10mm-3/8" CW
1
7447
Chainwheel -lower-12mm-1/2" CW
1
7451
Chainwheel -upper-10mm-3/8" ACW
1
7447
Chainwheel -upper-12mm-1/2" ACW
1
7451
17
Retaining Clip
2
2311
18
Seal
1
SP2799
19
Bearing
1
SP0657
20
Spring CW
1
7037
Spring ACW
1
7436
21
Pressure Arm
1
7435
22
Deckplate CW
1
7430
Deckplate ACW
1
7431
23
Gasket
1
7515
24
Stud - 90TDC
5
5225
Stud - 190TDC
5
7482
25
Washer
5
3843
26
Spring Washer
9
SP0466
27
Nut - M10
5
SP0371
28
Spring
1
7458
29
Pawl
1
7456
30
Washer
1
SP0413
