©2005 Maytag Services 16025911 Rev. 0 17
To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
!
8. Remove Inner Door Glass.
9. Remove outer door viewing panel. Insert screwdriver
in slot to disengage latch.
Interior Light
1. Disconnect power supply to unit.
2. Remove Lens screw and Lens. Bulb is a screw in
base 10W 120V AC.
Top Removal
1. Disconnect power supply to unit.
2. Remove 2 10mm screws from dryer back.
3. Slide Top Cover towards the rear and lift from unit.
