Maytag MDE9700A - Disassembly Procedures; Moisture Sensor Removal Procedure; Drive Belt Removal

22 16025911 Rev. 0 ©2005 Maytag Services
To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
!
9. Lift Bulkhead from Cabinet and remove.
Moisture Sensor Removal
1. Disconnect power supply to unit.
2. Remove Top Cover.
3. Remove Console.
4. Remove Front Panel.
5. Disconnect Moisture Sensor wire harness.
6. Remove sensor attachment screw.
Belt Removal
1. Disconnect power supply to unit.
2. Remove Top Cover.
3. Remove Console.
4. Remove Front Panel.
5. Remove belt from Idler Pulley
