Maytag MDE9700A - Disassembly Procedures; Gas Dryer Burner Removal

28 16025911 Rev. 0 ©2005 Maytag Services
To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
!
Burner Removal
1. Disconnect power supply to unit.
2. Shut off gas supply.
3. Disconnect gas line.
4. Remove two screws securing burner to bracket.
To avoid risk of personal injury or death; shut off gas
supply to unit before servicing Burner Assembly.
WARNING
!
NOTE: The Igniter Bar is fragile. Be careful not to
damage Igniter when removing Burner
Assembly.
5. Remove the two screws attaching the housing to the
burner bracket. The screws are recessed from view.
6. Slide Burner Assembly from dryer.
