20 16025911 Rev. 0 ©2005 Maytag Services
To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
6. Slide Heater Assembly out the front of dryer..
7. Remove the wiring terminals from the Heater
Assembly.
8. Reinstall by aligning the tabs on the back bulkhead
with the notches in the Heater Assembly .
To Next Page
