Maytronics Dolphin CLASSIC 13 - Clean the Impeller

12
CLASSIC 13 / CLASSIC 13+ | User Instructions
8.3 Clean the Impeller
Unplug the power supply before any servicing activity.
WARNING
If there is debris trapped in the impeller it should also be cleaned as follows.
1. Dismantle the impeller cover (images 7.3.1, 7.3.2, 7.3.3)
2. Clean around the impeller housing (image 7.3.4)
3. Reassemble.
Warning: Use a Phillips screwdriver only, not an electric screwdriver.
2
1
3
7.3.1 7.3.2
7.3.3 7.3.4
7.3.5 7.3.6
