8-23
Maintenance and Care
Owner Maintenance
Form No. 8S06-EA-03H
2. Pull down the blade rubber and slide it
out of the blade holder.
3. Remove the metal stiffeners from the
blade rubber and install them in new
blades.
4. Carefully insert the new blade rubber.
Then install the blade assembly in the
reverse order of removal.
Don’t bend the stiffeners. You need to
use them again.
Pull out
Stiffeners
CAUTION
J16R_8S06-EA-03H_Edition1.book Page 23 Wednesday, July 9, 2003 4:19 PM
