ON-BOARD DIAGNOSTIC [LF]
01-02–22
*
1
:MT
*
2
: California emission regulation applicable model
*
3
: With ABS, DSC HU/CM
*
4
: MT without ABS/DSC
*
5
: AT without ABS/DSC
End Of Sie
SELTESTDTC N/A Diagnostic trouble codes N/A N/A
SHRTFT1 ← Short term fuel trim (front) % N/A
SHRTFT12 ← Short term fuel trim (rear) % N/A
SPARKADV ← Ignition timing ° 2S
test ← Test mode Off/On N/A
TIRESIZE ← Tire revolution per mile rev/mile N/A
TP REL ← Throttle position signal (relative value) % N/A
TP1
←
TP sensor No.1
%
2AK
← V
TP2
←
TP sensor No.2
%
2AL
← V
TPCT ← TP sensor voltage at CTP V N/A
VPWR ← Battery positive voltage V 1BA
VSS
←
Vehicle speed KPH
2O
*4
←
1AM
*3, 5
,
1AI
*3, 5
VT ACT1 ← Actual valve timing ° 2E
VT DIFF1 ←
Difference between target valve timing and actual
valve timing
° N/A
VT DUTY1 ← OCV control) % 2E
Item
definition Unit/Condition
PCM
terminal
07MY 06MY
