MB ZTS - Optional Equipment; Dirt Deflector Installation

13
Publication: ZTS-080812
M-B Companies, Inc. 11/15/12
INTRODUCTIONOPTIONAL EQUIPMENT
DIRT DEFLECTOR INSTALLATION
See Figure 13 Dirt Deector Installation.
1. Position deector straps (2) over broom hood (1) and secure
each strap with one bolt (3) washer (4) and nut (5) in the top
hole of the strap and broom hood.
2. Attach strap support (6) to each deector strap. Position the
support strap at the lower edge of the deector strap and secure
with one bolt (3) and nut (5) in each support strap.
3. Position the deector (7) and upper support strap (8) over the
broom hood and deector strap assembly. Secure the deector
through the second hole at the top of the deector strap and
broom hood using one bolt (9), two washers (4) and a nut (5).
1
2
3
4
5
6
7
8
9
4
3
5
Figure 13 Dirt Deector Installation
