MB ZTS - Controls and Features; Broom Angle and Lift Controls

11
Publication: ZTS-080812
M-B Companies, Inc. 11/15/12
INTRODUCTIONCONTROLS AND FEATURES
The broom will push debris forward or to either side depending on the
position angle. The broom may need to be raised to adjust the angle
If the angle adjustment is manual:
1. Pull on the angle lock cable to release the head.
2. Use the swing control rod to position the broom head. The
broom may need to be raised to adjust the angle.
3. Release the angle lock cable. The lock pin will drop into the
position opening.
If the angle adjustment uses the electric actuator:
1. The controls mounted to the handlebar will actuate the
movement.
2. Press the rocker switch to move.
The lifting and lowering of the attachment may be controlled manually
or electrically.
If the lift/lower is manually controlled:
1. Use the mower deck hand lever to lift/lower.
2. Consult tractor Owner's manual for operation.
If the lift/lower is electrically controlled:
1. Use the electric rocker switch on the handlebar to actuate.
2. Press the rocker switch to lift or lower.
