INTRODUCTIONPARTS LIST
BROOM HEAD ASSEMBLY
Item Part Number Description Qty
1 100-140487 Caster Wheel, 5" 3/4" Expandable Stem 2
2 106-169430 Cable, Control Swing, MCD 1
3 206-72100 Grease Zerk 1/4-28 1
4 311-11500 HHCS 0.25-20 UNC x 1.500 2
5 311-31750 HHCS 3/8-16 UNC x 1.750 1
6 351-30000 Washer, Lock - 3/8 YLW Zinc PL 4
7 370-92047 Carriage Bolt 3/8-16 UNC x 1 4
8 371-169215 Nut 1/4-20 Clip-On, Tapped Hole 1
9 371-81297 Nut, Hex, ESNA, 3/8-16 UNC 5
10 371-81299 Nut, Hex, ESNA, 1/4-20 NC 2
11 371-81807 Nut, Hex, 10-24 1
12 380-133671 Pin, Clevis 1/2 x 2-1/2 2
13 380-140544 Pin, Swing MCD, Trigger Release 1
14 382-140710 Spring, Compression 0.51" OD x 3.5" Long 1
15 401-172238 Tube, Caster 2
16 401-172282 Guard, PTO, ZTS 1
17 401-172692 Rod Swing CTRL 1
18 410-172251 Caster Bracket WU 2
19 410-172538 Swing Tube Assy, ZTS 1
20 430-97620 Head Assembly, ZTS 60" 1
21 430-97622 ZTS Mounting Frame Group 1
22 430-97642 Core Assembly 5' ZTS, Poly 2
23 708-176177 Actuator, Linear 4" Stroke 1
