3. Push the arrow buttons and the OK button.
Select language, country, date, time. Set the
Wizard
and the PIN code. Refer to
Wizard
on page 23
.
Note: It is not possible to use 0000 as PIN
code.
4. Push the Start button and close the hatch to
initiate the guide calibration.
Note: If the battery is too low, the product
needs to charge the batteries fully before the
guide calibration starts. Refer to
Guide
calibration on page 23
.
3.9.3 Guide calibration
The calibration process is automatic and sets as
wide guide corridor as possible to reduce the risk
of tracks forming on the lawn.
Note: The product always runs within the guide
corridor but it alternates the distance to the guide
wire.
The guide calibration starts when the product
reaches the starting point. The product moves
away perpendicular from the guide wire at the left
side (as seen when facing the charging station)
for a maximum distance of 1.35 m / 4.4 ft. or until
it hits the boundary wire or an obstacle. This
distance is set as the maximum corridor width.
When the guide calibration is completed, the
product runs along the guide wire to the point
where the guide wire is connected to the
boundary wire. If the guide calibration is
successful, the product then starts to mow.
3.9.3.1 To redo the calibration
1. Push the Menu button for 3 seconds to enter
the
Quick info
menu.
2. Use the arrow buttons and the OK button to
move through the menu structure
Advanced
> Calibrate > Guide calibration
.
3. Place the product in the charging station.
4. Push the Start button to start the automatic
calibration.
3.10 To do the product settings
All commands and settings for the product are
done via the control panel. The control panel
consists of a display and a keypad, and all
functions are accessed through the menus. The
functions have factory settings to suit most work
areas, but the settings can be adapted to the
unique situation for each work area.
3.10.1 Menu structure
The main menu contains:
•
Lawn Shield
•
Security
•
Installation
•
General
Refer to
Menu structure overview on page 7
.
3.10.2 To get access to the menu
1. Push the STOP button.
2. Use the up/down arrow buttons and the OK
button to enter the PIN code.
3. Push the Settings button.
3.10.3 To do the schedule settings
You can set the schedule in 4 ways:
• Set the schedule by using the wizard. Refer
to
Wizard on page 23
.
• Day mode
• Night mode
• Set the schedule in the Advanced menu.
Refer to
To set the schedule on page 24
.
Note:
The lawn should not be cut too often to
obtain the best result. If the product is allowed to
operate too much, the lawn may appear
flattened. The product is also subjected to
unnecessary wear.
3.10.3.1 To get access to the schedule menu
1. Push the STOP button.
2. Use the up/down arrow buttons and the OK
button to enter the PIN code.
3. Push the Schedule button.
3.10.3.2 Wizard
The wizard is a quick tool to find suitable
schedule settings for your lawn.
1. Do steps 1–3 in
To get access to the
schedule menu on page 23
.
1411 - 001 - 18.12.2019
Installation - 23
