8 Technical data
8.1 Technical data
Data ROB S400, ROB S500, ROB S600
Dimensions
Length, cm 55
Width, cm 38
Height, cm 23
Weight, kg 7.3
Electrical system ROB S400, ROB S500, ROB S600
Battery, Lithium-Ion 18 V/2.1 Ah Art.No 584 85 28-01, 584 85 28-02, 593 11 40-01, 593
11 40-02
Battery, Lithium-Ion 18 V/2.0 Ah Art.No 590 21 42-02
Battery, Lithium-Ion 18.25 V/2.0 Ah Art.No 590 21 42-03
Power supply, V/28 V DC 100-240
Low voltage cable length, m 5
Mean energy consumption at maximum use 5 kWh/month in a 500 m
2
work area
Charge current, A DC 1.3
Average mowing time, min 65
Average charging time, min 60
Boundary wire antenna ROB S400, ROB S500, ROB S600
Operating Frequency Band, Hz 300-80000
Maximum Radio-frequency power, mW @60m
1
<25
1
Maximum active output power to antennas in the frequency band in which the radio equipment
operates.
50 - Technical data
1411 - 001 - 18.12.2019
