SmarTraq
26 Manual # 42-02-D008 Rev. A2
Table 7. Center Parting Doors without Reopening Device (Nudging)
26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 64 66
(1) Code Zone Distance (inch) 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
100 0.72 0.79 0.85 0.92 0.99 1.05 1.12 1.18 1.25 1.31 1.38 1.44 1.51 1.58 1.64 1.71 1.77 1.84 1.90 1.97 2.04
150 0.88 0.97 1.05 1.13 1.21 1.29 1.37 1.45 1.53 1.61 1.69 1.77 1.85 1.93 2.01 2.09 2.17 2.25 2.33 2.41 2.49
200 1.02 1.11 1.21 1.30 1.39 1.49 1.58 1.67 1.76 1.86 1.95 2.04 2.14 2.23 2.32 2.41 2.51 2.60 2.69 2.79 2.88
250 1.14 1.25 1.35 1.45 1.56 1.66 1.77 1.87 1.97 2.08 2.18 2.28 2.39 2.49 2.60 2.70 2.80 2.91 3.01 3.12 3.22
300 1.25 1.37 1.48 1.59 1.71 1.82 1.93 2.05 2.16 2.28 2.39 2.50 2.62 2.73 2.84 2.96 3.07 3.19 3.30 3.41 3.53
350 1.35 1.47 1.60 1.72 1.84 1.97 2.09 2.21 2.33 2.46 2.58 2.70 2.83 2.95 3.07 3.19 3.32 3.44 3.56 3.69 3.81
400 1.44 1.58 1.71 1.84 1.97 2.10 2.23 2.36 2.50 2.63 2.76 2.89 3.02 3.15 3.28 3.42 3.55 3.68 3.81 3.94 4.07
450 1.53 1.67 1.81 1.95 2.09 2.23 2.37 2.51 2.65 2.79 2.93 3.07 3.20 3.34 3.48 3.62 3.76 3.90 4.04 4.18 4.32
500 1.62 1.76 1.91 2.06 2.20 2.35 2.50 2.64 2.79 2.94 3.08 3.23 3.38 3.52 3.67 3.82 3.97 4.11 4.26 4.41 4.55
550 1.69 1.85 2.00 2.16 2.31 2.46 2.62 2.77 2.93 3.08 3.23 3.39 3.54 3.70 3.85 4.00 4.16 4.31 4.47 4.62 4.77
600 1.77 1.93 2.09 2.25 2.41 2.57 2.73 2.90 3.06 3.22 3.38 3.54 3.70 3.86 4.02 4.18 4.34 4.50 4.67 4.83 4.99
650 1.84 2.01 2.18 2.34 2.51 2.68 2.85 3.01 3.18 3.35 3.52 3.68 3.85 4.02 4.19 4.35 4.52 4.69 4.86 5.02 5.19
700 1.91 2.09 2.26 2.43 2.61 2.78 2.95 3.13 3.30 3.48 3.65 3.82 4.00 4.17 4.34 4.52 4.69 4.87 5.04 5.21 5.39
750 1.98 2.16 2.34 2.52 2.70 2.88 3.06 3.24 3.42 3.60 3.78 3.96 4.14 4.32 4.50 4.68 4.86 5.04 5.22 5.40 5.58
800 2.04 2.23 2.41 2.60 2.79 2.97 3.16 3.34 3.53 3.72 3.90 4.09 4.27 4.46 4.64 4.83 5.02 5.20 5.39 5.57 5.76
850 2.11 2.30 2.49 2.68 2.87 3.06 3.26 3.45 3.64 3.83 4.02 4.21 4.40 4.60 4.79 4.98 5.17 5.36 5.55 5.74 5.94
900 2.17 2.36 2.56 2.76 2.96 3.15 3.35 3.55 3.74 3.94 4.14 4.33 4.53 4.73 4.93 5.12 5.32 5.52 5.71 5.91 6.11
950 2.23 2.43 2.63 2.83 3.04 3.24 3.44 3.64 3.85 4.05 4.25 4.45 4.66 4.86 5.06 5.26 5.47 5.67 5.87 6.07 6.28
1000 2.28 2.49 2.70 2.91 3.12 3.32 3.53 3.74 3.95 4.15 4.36 4.57 4.78 4.98 5.19 5.40 5.61 5.82 6.02 6.23 6.44
1050 2.34 2.55 2.77 2.98 3.19 3.41 3.62 3.83 4.04 4.26 4.47 4.68 4.89 5.11 5.32 5.53 5.75 5.96 6.17 6.38 6.60
1100 2.40 2.61 2.83 3.05 3.27 3.49 3.70 3.92 4.14 4.36 4.57 4.79 5.01 5.23 5.45 5.66 5.88 6.10 6.32 6.53 6.75
1150 2.45 2.67 2.90 3.12 3.34 3.56 3.79 4.01 4.23 4.45 4.68 4.90 5.12 5.35 5.57 5.79 6.01 6.24 6.46 6.68 6.90
1200 2.50 2.73 2.96 3.19 3.41 3.64 3.87 4.10 4.32 4.55 4.78 5.01 5.23 5.46 5.69 5.92 6.14 6.37 6.60 6.83 7.05
NOTES:
(2) See Section 2.13.4.2.1 of ASME A17.1 Safety Code for Elevators for detail
(1) See Section 2.13.4.2.2 of ASME A17.1 Safety Code for Elevators for detail
Kinetic Energy Formula
M = Combined Weight of Car and Hoistway Doors and All Attached Equipment
V
= Speed in Feet Per Second
(2) Combined Weight
of Car and Hoistway
Doors and All
Attached Equipment
(lbs)
MINIMUM CLOSING TIME FOR CENTER PARTING DOORS WITHOUT RE-OPENING DEVICE (NUDGING) (sec)
Door Opening Width (inch)
M
2
32.2
V
