Fusion Equipment Safety
1 - 6
Heater is Hot
The heater is hot and will burn clothing and skin.
Keep the heater in its insulated heater stand or
blanket when not in use, and use care when
heating the pipe.
NOTICE: Use only a clean non-synthetic cloth such as a cotton
cloth to clean the heater plates.
TX00104-8-12-94
WR00030-2-10-93
Keep Machine Away From Edge of Ditch
Heavy equipment too close to a ditch can
cause the walls of the ditch to cave-in. Keep
the machine far enough away from the edge
of the ditch to prevent injury to personnel and
equipment from a cave-in.
TX01447-12-30-97
CD00408b-9-27-00
Do Not Attempt to Tow Fusion Machine
The machine is not designed for towing.
Attempting to tow the machine can result in
machine damage. Always transport the machine
by flat bed truck or similar means, and make sure
that unit is properly secured.
TX01888-11-15-00
CD00401b-9-27-00
0
100
200
300
400
500
600
700
800
900
1000
DIRECTIONAL
CONTROL
VALVE
FACING
PRESSURE
HEATING
PRESSURE
FUSING
PRESSURE
SELECTOR
VALVE
Operating Fusion Machine
Place fusion machine on as level ground as possible.
If it is necessary to operate machine on unlevel grade, make
sure that the ground is stable. Some unstable conditions may be
ice, snow, mud and loose gravel.
For operation safety, never operate the machine
on a grade steeper than 30 %. (A 3 foot
elevation change in 10 feet)
