Remove Facer From TracStar No.412
and No.618 Machine
Remove rear guide rod bracket.
Remove facer locking bolts.
Lift facer out of the carriage and set on cardboard or wood
blocks off of ground.
Attach rear guide rod bracket in the position shown.
TX01992-1-10-02
Special Operations - In Ditch
4 - 3
PH01907-11-15-00PH01936-11-15-00
PH01933-11-15-00
