McElroy TracStar 618 - Opening Fixed Jaws; Raise Pipe; Hydraulic Pipelifts

Raise Pipe
Raise the joined pipe using the pipe lift. Push down on the pipe
lift lever then release the latch. Pull the lever up to raise the pipe.
TX00382-9-16-94
Hydraulic Pipe Lifts
The TracStar
®
No.618 is equipped with two hydraulic pipe lifts
controlled by a valve mounted on the outer fixed jaw. When not
in use latch the valve in the down position.
TX01991-1-10-02
Opening Fixed Jaws
Open the fixed jaws.
TX00381-9-16-94
