McIntosh C1000

48
C1 CAP ELECT 220UF 25V 066507
C2 CAP ELECT 47UF 35V 066446
C3 CAP ELECT 220UF 25V 066507
C4 CAP MONO 100PF 100V 10% NPO 061341
C5 CAP MONO 100PF 100V 10% NPO 061341
C6 CAP ELECT 4.7UF 50V 066512
C7 CAP ELECT 10UF 50V 066445
C8 CAP ELECT 10UF 50V 066445
C16 CAP ELECT 47UF 35V 066446
C23 CAP ELECT 10UF 16V 066580
C24 CAP ELECT 10UF 16V 066580
C25 CAP ELECT 10UF 16V 066580
C26 CAP ELECT 10UF 16V 066580
C32 CAP MONO .1UF 50V 20% Z5U 061346
C33 CAP MONO .1UF 50V 20% Z5U 061346
C34 DIODE SIL 400 PIV @ 1.5A 070031
C35 CAP MONO .1UF 50V 20% Z5U 061346
C37 CAP ELECT 4.7UF 50V 066512
C38 CAP MONO 220PF 200V 10% NPO 061342
C39 CAP ELECT 10UF 50V 066445
C40 CAP MONO 100PF 100V 10% NPO 061341
C41 CAP MONO 100PF 100V 10% NPO 061341
C42 CAP MONO 22PF 200V 10% NPO 061339
C43 CAP MONO 22PF 200V 10% NPO 061339
C44 CAP ELECT 10UF 16V 066580
C45 CAP ELECT 10UF 16V 066580
C46 CAP ELECT 10UF 16V 066580
C47 CAP ELECT 10UF 16V 066580
C48 CAP ELECT 10UF 100VDC 066462
C50 CAP MONO .1UF 50V 20% Z5U 061346
C51 CAP MONO .1UF 50V 20% Z5U 061346
C54 CAP ELECT 10UF 50V 066445
C55 CAP ELECT 10UF 50V 066445
C56 CAP ELECT 10UF 50V 066445
C57 CAP ELECT 10UF 50V 066445
C58 CAP MONO 100PF 100V 10% NPO 061341
C59 CAP MONO 100PF 100V 10% NPO 061341
C60 CAP MONO 100PF 100V 10% NPO 061341
C61 CAP MONO 100PF 100V 10% NPO 061341
C62 CAP MONO 22PF 200V 10% NPO 061339
C63 CAP MONO 22PF 200V 10% NPO 061339
C65 CAP ELECT 10UF 100VDC 066462
C66 CAP MONO .1UF 50V 20% Z5U 061346
C69 CAP MONO .1UF 50V 20% Z5U 061346
C70 CAP ELECT 10UF 50V 066445
C71 CAP ELECT 10UF 50V 066445
C72 CAP MONO .1UF 50V 20% Z5U 061346
C73 CAP MONO .1UF 50V 20% Z5U 061346
C76 CAP ELECT 10UF 100VDC 066462
C78 CAP MONO 22PF 200V 10% NPO 061339
C79 CAP MONO 22PF 200V 10% NPO 061339
C80 CAP MONO 22PF 200V 10% NPO 061339
C81 CAP MONO 100PF 100V 10% NPO 061341
C82 CAP ELECT 10UF 100VDC 066462
C83 CAP MONO .1UF 50V 20% Z5U 061346
C84 CAP MONO .1UF 50V 20% Z5U 061346
C85 CAP MONO 100PF 100V 10% NPO 061341
C86 CAP ELECT 10UF 50V 066445
C87 CAP ELECT 10UF 16V 066580
C88 CAP ELECT 10UF 50V 066445
C89 CAP ELECT 10UF 50V 066445
C90 CAP ELECT 10UF 50V 066445
C91 CAP MONO .1UF 50V 20% Z5U 061346
C92 CAP MONO 100PF 100V 10% NPO 061341
C93 CAP MONO 100PF 100V 10% NPO 061341
C94 CAP MONO 100PF 100V 10% NPO 061341
C95 CAP MONO 100PF 100V 10% NPO 061341
C96 CAP ELECT 10UF 50V 066445
C97 CAP MONO 220PF 200V 10% NPO 061342
C98 CAP MONO 22PF 200V 10% NPO 061339
C99 CAP MONO 22PF 200V 10% NPO 061339
C100 CAP ELECT 10UF 100VDC 066462
C102 CAP MONO .1UF 50V 20% Z5U 061346
C103 CAP MONO .1UF 50V 20% Z5U 061346
C106 CAP ELECT 47UF 35V 066446
C107 CAP ELECT 47UF 35V 066446
R207 RES MF 182 OHM 1/4W 1% 144579
R208 RES MF 182 OHM 1/4W 1% 144579
R214 RES MF 2.21K 1% 1/4W 144584
U1 IC STEREO DGTL VOLUME CONTROL 133331
U2 IC SHFT REG SER-PAR 133186
U3 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U3) SOCKET IC 18-PIN DIP 178184
U4 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U4) SOCKET IC 18-PIN DIP 178184
U5 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U5) SOCKET IC 18-PIN DIP 178184
U6 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U6) SOCKET IC 18-PIN DIP 178184
U7 IC SHFT REG SER-PAR 133186
U8 IC SHFT REG SER-PAR 133186
U9 IC SHFT REG SER-PAR 133186
U10 IC SHFT REG SER-PAR 133186
U11 IC OPERATIONAL AMP LOW NOISE 133067
U12 IC OPERATIONAL AMP LOW NOISE 133067
U13 IC OPERATIONAL AMP LOW NOISE 133067
U14 IC OPERATIONAL AMP LOW NOISE 133067
U15 IC OPERATIONAL AMP LOW NOISE 133067
U16 IC OPERATIONAL AMP LOW NOISE 133067
U17 IC OPERATIONAL AMP LOW NOISE 133067
U18 IC OPERATIONAL AMP LOW NOISE 133067
U19 IC OPERATIONAL AMP LOW NOISE 133067
U20 IC REGULATOR 5V 133250
U21 IC -5V REGULATOR 133253
U22 IC REGULATOR 5V 133250
U23 IC -5V REGULATOR 133253
U24 IC OPERATIONAL AMP LOW NOISE 133067
U25 IC OPERATIONAL AMP LOW NOISE 133067
U26 IC SHFT REG SER-PAR 133186
U27 IC OPERATIONAL AMP LOW NOISE 133067
U28 IC OPERATIONAL AMP LOW NOISE 133067
U29 IC OPERATIONAL AMP LOW NOISE 133067
U30 IC OPERATIONAL AMP LOW NOISE 133067
U31 IC OPERATIONAL AMP LOW NOISE 133067
U32 IC OPERATIONAL AMP LOW NOISE 133067
V3 SOCKET 9 PIN TUBE CERAMIC 178170
V4 SOCKET 9 PIN TUBE CERAMIC 178170
ASSY INSERTION PCB MAIN LEFT 701081
MAIN LEFT PCB 050109 (Cont’d)
Ref. No. Description Part No.
PARTS LIST Cont’d
Ref. No. Description Part No.
MAIN RIGHT PCB 050111

