McIntosh C1000

TUBE PREAMPLIFIER
C1000
49
C111 CAP MONO .1UF 50V 20% Z5U 061346
C112 CAP ELECT 10UF 50V 066445
C113 CAP MONO .1UF 50V 20% Z5U 061346
C114 CAP POLYPROP 0.22UF 400V 20% 064438
C115 CAP POLYPROP 0.22UF 400V 20% 064438
C116 CAP MONO .1UF 50V 20% Z5U 061346
C117 CAP ELECT 10UF 50V 066445
C118 CAP MONO 100PF 100V 10% NPO 061341
C119 CAP MONO 100PF 100V 10% NPO 061341
C120 CAP MONO 22PF 200V 10% NPO 061339
C121 CAP MONO 22PF 200V 10% NPO 061339
C122 CAP POLY .047UF 10% 1000VDC 064434
C123 CAP POLY .047UF 10% 1000VDC 064434
C125 CAP MONO 22PF 200V 10% NPO 061339
C126 CAP MONO 22PF 200V 10% NPO 061339
C127 CAP ELECT 10UF 100VDC 066462
C129 CAP MONO .1UF 50V 20% Z5U 061346
C130 CAP MONO .1UF 50V 20% Z5U 061346
C133 CAP MONO 220PF 200V 10% NPO 061342
C134 CAP MONO .1UF 50V 20% Z5U 061346
C136 CAP MONO 1000PF 50V 10% NPO 061344
C137 CAP ELECT 220UF 25V 066507
C138 CAP ELECT 220UF 25V 066507
C139 CAP MONO 1000PF 50V 10% NPO 061344
C141 CAP MONO 1000PF 50V 10% NPO 061344
C143 CAP MONO 1000PF 50V 10% NPO 061344
C145 CAP MONO 22PF 200V 10% NPO 061339
C146 CAP MONO 22PF 200V 10% NPO 061339
C147 CAP ELECT 10UF 100VDC 066462
C149 CAP MONO .1UF 50V 20% Z5U 061346
C150 CAP MONO .1UF 50V 20% Z5U 061346
C153 CAP ELECT 100UF 25V 066573
C154 CAP ELECT 100UF 25V 066573
C155 CAP MONO 22PF 200V 10% NPO 061339
C156 CAP ELECT 10UF 100VDC 066462
C157 CAP MONO .1UF 50V 20% Z5U 061346
C158 CAP MONO .1UF 50V 20% Z5U 061346
C159 CAP MONO 22PF 200V 10% NPO 061339
C160 CAP ELECT 10UF 100VDC 066462
C161 CAP ELECT 100UF 25V 066573
C162 CAP MONO .1UF 50V 20% Z5U 061346
C163 CAP MONO .1UF 50V 20% Z5U 061346
C164 CAP MONO 22PF 200V 10% NPO 061339
C165 CAP MONO .1UF 50V 20% Z5U 061346
C166 CAP MONO .1UF 50V 20% Z5U 061346
C167 CAP ELECT 47UF 35V 066446
C168 CAP MONO 22PF 200V 10% NPO 061339
C177 CAP MONO .1UF 50V 20% Z5U 061346
C108 CAP ELECT 10UF 250V 066558
C124 CAP ELECT 22UF 100V 066574
D3 DIODE SILICON 070174
D4 DIODE SILICON 070174
D7 DIODE SILICON 070174
D8 DIODE SILICON 070174
D9 DIODE SILICON 070174
D10 DIODE SILICON 070174
DS1 LED GREEN 3MM HI INTENSITY 058172
(DS1) LED SPACER .125 THK 017672
DS1 LED GREEN 3MM HI INTENSITY 058172
(DS2) LED SPACER .125 THK 017672
GP1 BRACKET PCB CARD MOUNTING 003611
(GP1) RIVET 1/8X3/16 STEEL 108011
GP2 BRACKET PCB CARD MOUNTING 003611
(GP2) RIVET 1/8X3/16 STEEL 108011
J1 JACK PHONO GOLD 117862
J2 JACK PHONO GOLD 117862
J3 JACK PHONO GOLD 117862
J4 JACK PHONO GOLD 117862
J5 JACK PHONO GOLD 117862
J6 JACK PHONO GOLD 117862
J7 JACK PHONO GOLD 117862
J8 CONN 12 PIN FFC 117720
J9 HEADER SHROUDED 2 ROW 26 PIN V 117870
J10 HEADER 2 PIN LATCHING 117766
J11 CONN 12 PIN FFC 117720
J12 CONN 12 PIN FFC 117720
J13 HEADER 2 PIN LATCHING 117766
J14 CONN 12 PIN FFC 117720
J15 CONN 12 PIN FFC 117720
J16 CONN 12 PIN FFC 117720
J17 CONN 12 PIN FFC 117720
J18 HEADER 2 PIN LATCHING 117766
J19 HEADER 2 PIN LATCHING 117766
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1C 5V 125 OHM 087056
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1A 5V 500 OHMS 087050
K8 RELAY REED FORM 1A 5V 500 OHMS 087050
K9 RELAY REED FORM 1A 5V 500 OHMS 087050
K10 RELAY REED FORM 1A 5V 500 OHMS 087050
K11 RELAY REED FORM 1A 5V 500 OHMS 087050
K12 RELAY REED FORM 1A 5V 500 OHMS 087050
K13 RELAY REED FORM 1A 5V 500 OHMS 087050
K14 RELAY REED FORM 1A 5V 500 OHMS 087050
K15 RELAY REED FORM 1C 5V 125 OHM 087056
K16 RELAY REED FORM 1A 5V 500 OHMS 087050
K17 RELAY REED FORM 1C 5V 125 OHM 087056
K18 RELAY REED FORM 1A 5V 500 OHMS 087050
K19 RELAY REED FORM 1A 5V 500 OHMS 087050
K20 RELAY REED FORM 1A 5V 500 OHMS 087050
K21 RELAY REED FORM 1A 5V 500 OHMS 087050
K22 RELAY REED FORM 1A 5V 500 OHMS 087050
K23 RELAY REED FORM 1A 5V 500 OHMS 087050
K24 RELAY REED FORM 1A 5V 500 OHMS 087050
K25 RELAY REED FORM 1A 5V 500 OHMS 087050
MC1 ASSEMBLY PCB PHONO MC 050104
Q1 TRANSISTOR NPN SILICON 132317
Q2 TRANSISTOR SI NPN 25V 132257
Q3 TRANSISTOR SI NPN 25V 132257
Q4 TRANSISTOR PNP 132304
Q5 TRANSISTOR PNP 132304
Q6 TRANSISTOR N JFET 132319
Q7 TRANSISTOR PNP 132304
Q8 TRANSISTOR N JFET 132319
Q9 TRANSISTOR PNP 132304
Q10 TRANSISTOR N JFET 132319
Q11 TRANSISTOR PNP 132304
Q12 TRANSISTOR N JFET 132319
MAIN RIGHT PCB 050111 (Cont’d)
Ref. No. Description Part No.
PARTS LIST Cont’d
Ref. No. Description Part No.
