14
Remote Control Push-Buttons
Press to Power the
C2300 ON or OFF
Selects one of the nine
available Audio Sources
Selects a Disc Player, Music Server
or Tape Recorder Function and also
performs various functions on a
variety of McIntosh Components
Use to select tuner presets, disc
tracks or any numbered operation
Mutes the audio
Adjusts the volume level up or down
Selects On Screen Functions on a
variety of McIntosh Components
Selects Output 1, AM Tuner Operat
-
ing Functions and Disc Selection on
certain McIntosh Disc Players
Selects Output 2, FM Tuner Operat
-
ing Functions and Track Selection
on certain McIntosh CD Players
Press to REVIEW Tuner Station
Presets and select certain functions
on a variety of McIntosh Compo-
nents
Press MODE to switch between
Stereo and Mono Modes
Press TRIM and then the LEVEL
Push-buttons to select and adjust
various functions
Turns AC Power ON or OFF to
certain McIntosh Components when
connected via the Data Port
Selects Functions for McIntosh
Home Controller and as a “shift”
key when used with the AM or FM
push-buttons to select Output (Spkr)
1 or 2
Note: Push-buttons whose function is not identified above
are for use with other McIntosh Products.
Press to Power ON
the C2300
Press to Power OFF
the C2300
LED illuminates during the time a
remote command is sent to the C2300
Switches OFF the
entire C2300 System
Selects the FF (Fast Forward) or
REWind Mode on Disc Player,
Music Server or Tape Recorder;
tunes Up or Down the AM/FM
Dial
Press to listen to the
selected Record Out
Signal
Scrolls through the available
C2300 Inputs
