McIntosh C2300 User Manual

8
Rear Panel Connections
Rear Panel Connections
The identification of Rear Panel Connections for the
C2300 Tube Preamplifier is located on a separate folded
sheet contained in the Owner’s Manual Packet.
Refer to separate sheet “Mc2A” for the Rear Panel Connec-
tions.
C2300 Tube Preamplifer Rear Panel

McIntosh C2300 Specifications

General

Output level	45 mV
Amplifier class	-
Frequency range	10 - 100000 Hz
Input sensitivity	4.5 mV
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	93 dB
Total Harmonic Distortion (THD)	0.08 %
XLR in	Yes
XLR out	3
Headphone outputs	1
Line inputs (RCA)	6
Line outputs (RCA)	4
Headphone connectivity	6.3 mm
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	75 W
Package weight	20410 g

Weight and Dimensions

Depth	457.2 mm
Width	444.5 mm
Height	193.7 mm
Weight	13.41 g
