TM2-11

1. Momentarily

press and

release the

Front Panel

STORE Push-

button. The Front Panel Information Display will indi-

cate “PRESET 1: AVAILABLE”, which is the first of 9

Preset Numbers to be assigned. Refer to figures TM2-

21 and TM2-5. The Station to be entered into memory

may also be

assigned to

a different

Preset Num-

ber (2-9) by

rotating the TUNE (TRIM ADJUST) Control to select

the desired Preset Number.

Notes: 1. Presets are automatically assigned in order

from 1 to 9 unless a different Preset Number is

selected.

2. To exit without entering a new Preset into

memory, momentarily press the Front Panel

EXIT (STORE) Push-button.

2. To enter the station into menory press and hold in the

STORE Push-button until the Front Panel Information

Display indicates “PRESET STORED” then release

the STORE Push-button. Refer to figure TM2-22. The

just entered

Station Preset

will be as-

signed Preset

Number 1 (or

the Preset number you selected) and is displayed on the

How to Operate the MA6600 Tuner, con’t

Figure TM2-5

91.5-FM ST ¦

Front Panel Information Display. Refer to figure TM2-

23.

3. Assign addi-

tional station

Presets by

performing

steps 1 and 2.

Note: If all 9 Presets are assigned and the STORE Push-

button is pressed, the display will indicate the sta-

tion selected for Preset Number 1. Refer to figure

TM2-24 .

4. To verify

the Station

Preset(s) just

entered into

memory,

rotate the Front Panel TUNE (TRIM ADJUST) Con-

trol; using the Remote Control press the NEXT : or

BACK 9 Push-buttons to cycle through and confirm

your preset assignments.

Clearing Presets

5. Select the Station Preset to be removed by using the

Front Panel TUNE (TRIM ADJUST) Control or using

the Remote Control NEXT : or BACK 9 Push-

buttons.

6. Press and hold in the Front Panel STORE Push-button

until the Front Panel Information Display indicates

“PRESET CLEARED” then release the STORE Push-

button. Refer to figure TM2-25.

Figure TM2-20

91.5-FM ST ¦

NO PRESETS AVAIALABE

Figure TM2-21

91.5-FM ST ¦

PRESET 1: AVAILABLE

Figure TM2-22

91.5-FM ST ¦

PRESET STORED

Figure TM2-23

P1 91.5-FM ST ¦

Figure TM2-24

P9 105.7-FM ST ¦

PRESET 1: 91.5 MHz

Figure TM2-25

P1 91.5-FM ST ¦

PRESET CLEARED

Other manuals for McIntosh MA6600

Owner's Manual28 pages

Connection Diagrams2 pages

Questions and Answers:

Need help?

Do you have a question about the McIntosh MA6600 and is the answer not in the manual?

McIntosh MA6600 Specifications

General

Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	115 dB
Total Harmonic Distortion (THD)	0.005 %
XLR in	Yes
Audio (L/R) out	8
Line inputs (RCA)	14
Line outputs (RCA)	6
Purpose	Home
Product color	Black
Connectivity technology	Wired
Maximum current	4.4 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Package weight	42300 g
