McIntosh MA6600 User Manual

16
The MA6600 responds to Remote Control Codes
NORMal (default) or ALTernate. The ALTernate
Codes are selected when the MA6600 is used with
another McIntosh Remote Controllable Preamplifier,
thus preventing both units from responding to the
same Remote Control Commands.
1. Press the MONO/SETUP Push-button until the
Setup Mode is active. Then press the MONO/
SETUP Push-button to select the Setup Menu
item “SETUP: REMOTE”. Refer to figure 14-1.
2. Rotate
the
TRIM
ADJUST
Control
until “REMOTE CODES: ALT” appears on the
Front Panel Information Display. Refer to figure
14-2.
3. Press the
STORE/
EXIT
Push-
button to exit the Setup Mode.
Remote Control Selection
Figure 14-2
SETUP: REMOTE
REMOTE CODES: ALT
Figure 14-1
SETUP: REMOTE
REMOTE CODES: NORM
Setup, con’t

McIntosh MA6600 Specifications

General

Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	115 dB
Total Harmonic Distortion (THD)	0.005 %
XLR in	Yes
Audio (L/R) out	8
Line inputs (RCA)	14
Line outputs (RCA)	6
Purpose	Home
Product color	Black
Connectivity technology	Wired
Maximum current	4.4 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Package weight	42300 g

Weight and Dimensions

Depth	558.8 mm
Width	444.5 mm
Height	193.7 mm
Weight	34100 g
