8
Connecting Components
The MA6600 has the ability to automatically switch
power On/Off to McIntosh Source Components via
the Power Control connections. The Data Port Con-
nections allow for the remote operation of basic
functions using the MA6600 Remote Control. With
an external sensor connected to the MA6600, re-
mote control operation of the system is possible from
another room and/or when the MA6600 is located in a
cabinet with the doors closed.
The connection instructions below, together with
the MA6600 Input and Output Connection Diagrams
located on the separate folded sheet “Mc1A/1B”, are
an example of a typical audio system. Your system
may vary from this, however the actual components
would be connected in a similar manner. For addition-
al information refer to “Connector and Cable Informa-
tion” on page 4.
Power Control Connections:
1. Connect a Control Cable from the MA6600 POW-
ER CONTROL MAIN Jack to the Power Control
In on the McIntosh Turntable.
2. Connect a Control Cable from the McIntosh
Turntable Power Control Out Jack to the McIntosh
Audio/Video Player Power Control In Jack.
3. Connect a Control Cable from the McIntosh
Audio/Video Player Power Control Out Jack to the
McIntosh SACD/CD Player Power Control In Jack.
4. Connect a Control Cable from the McIntosh
SACD/CD Player Power Control Out Jack to the
McIntosh Music Server Power Control In Jack.
5. Optionally connect a Control Cable from the
MA6600 POWER CONTROL OUTPUT 2 Jack to
the McIntosh Power Amplifier (Secondary Room)
Power Control In Jack.
6. Connect any additional McIntosh Components in
a similar manner, as outlined in steps 1 thru 4.
Data Control Connections:
7. Connect a Control Cable from the MA6600 CD
DATA PORT Jack to the McIntosh SACD/CD
Player Data In Jack.
8. Connect a Control Cable from the MA6600
SERVER DATA PORT Jack to the McIntosh Mu-
sic Server Data In Jack.
9. Connect a Control Cable from the MA6600 DVD
DATA PORT Jack to the McIntosh Audio/Video
Player Data In Jack.
10. Connect any additional McIntosh Components in
a similar manner, as outlined in steps 7 thru 9.
Sensor Connections:
11. Connect a RG59U or RG6U Cable from the
MA6600 EXT SENSOR “F” Connector to the
McIntosh Sensor “F” Connector.
Audio Connections:
12. Connect Balanced Cables from the MA6600 CD
1 INPUT Jacks to the McIntosh SACD/CD Player
Fixed Balanced Output Jacks.
13. Connect an Audio Cable from the MA6600
SERVER INPUT Jacks to the McIntosh Music
Server Output Jacks.
14. Connect an Audio Cable from the MA6600 REC
OUTPUT Jacks to the McIntosh Music Server
Input 3 Jacks.
15. Connect Audio Cables from the MA6600 DVD
INPUT Jacks to the McIntosh Audio/Video Player
Output Jacks.
16. Connect the Audio Cables coming from the Turn-
table to the MA6600 PHONO INPUT Jacks.
17. Optionally, connect Audio Cables from the
MA6600 OUTPUT 2 Jacks to the McIntosh Power
Amplifier (Secondary) Input Jacks.
18. Connect any additional McIntosh Components in a
similar manner, as outlined in steps 12 thru 17.
Ground Connections:
19. Connect the Ground Cable coming from the Turn-
table to the MA6600 GND Binding Post.
AC Power Cords Connections:
20. Connect the MA6600 and any remaining com-
ponents’ AC Power Cords to a live AC outlet as
illustrated.
