15
5. Connect the MA/MAC6700 power cord to an ac-
tive AC outlet.
Spade Lug or Wire Connections:
6. Connect the Loudspeaker hookup cables to the
MA/MAC6700 Negative Output Terminal and
Positive Output Terminal indentified as 2Ω
(ohms), 4Ω (ohms) or 8Ω (ohms) connection to
match the impedance of the Loudspeaker, being
careful to observe the correct polarities. Insert
the spade lug connector or prepared section of the
cable end into the terminal side access hole, and
tighten the terminal cap until the cable is firmly
clamped into the terminals so the lugs or wire can-
not slip out. Refer to fgures L and M.
Note: The illustration located on the separate folded
sheet “Mc2B” is for connection to an 8Ω
(ohms) Loudspeaker.
If the Loudspeaker’s impedance is in-between the
available connections, use the nearest lower im-
pedance connection. Refer to “General Informa-
tion” Note 7 on page 4 for additional information.
WARNING: Loudspeaker terminals are hazard-
ous live and present a risk of electric
shock. For additional instruction on
making Loudspeaker Connections con-
tact your McIntosh Dealer or McIn-
tosh Technical Support.
7. Connect the MA/MAC6700 power cord to an ac-
tive AC outlet.
Connecting Loudspeakers
Figure L
Figure M
