MA/MAC6700 Amplifier and MAC6700 TM2, TM3 Tuner Specifications
TM3 - FM Specifications
Tuning Range
87.5MHz - 108.0MHz (Europe)
87.9MHz - 107.9MHz (USA)
76MHz - 90MHz (Japan)
FM Channel Spacing
200kHz (USA, Japan)
50kHz (Europe)
Antenna Input
75 Ohms, Type “F” Coax connector
Useable Sensitivity
2.2uV (18.1dBf)
50dB Quieting Sensitivity
1.5uV (14.8dBf)
Signal To Noise Ratio
Mono: 70dB
Stereo: 68dB
Frequency Response
±1dB 20 to 15,000Hz
Harmonic Distortion
Mono: 0.4%
Stereo: 0.8%
Channel Selectivity
60dB Adjacent Channel
66dB Alternate Channel
Stereo Separation
38dB
TM3 - AM Specifications
AM Tuning Range
522kHz - 1602kHz (Europe)
530kHz - 1710kHz (USA)
522kHz - 1611kHz (Japan)
AM Channel Spacing
10kHz (USA)
9kHz (Europe, Japan)
Sensitivity
350uV/m
Signal To Noise Ratio
50dB
Frequency Response
0dB, -6dB 50Hz to 3,000Hz
Harmonic Distortion
0.5%
Selectivity
45dB Adjacent Channel
TM3 - General Specifications
FM Antenna Input
75 ohms, Type “F” Coax connector
AM Antenna Input
Balanced, RJ45 connector
(for use only with supplied McIntosh RAA2 Remote
AM Antenna)
RAA2 Connection Cable
20 foot (6.09m) 8 conductor straight-thru cable with an
TM2 - General Specifications
FM Antenna Input
75 ohms, Type “F” Coax connector
AM Antenna Input
Balanced, RJ45 connector
(for use only with supplied McIntosh RAA2 Remote
AM Antenna)
RAA2 Connection Cable
20 foot (6.09m) 8 conductor straight-thru cable with an
outer shield and RJ45 connectors on each end (shield-
ed CAT5 or CAT6 patch cable)
RAA2 Remote AM Antenna Overall Dimensions
Width is 6 inches (15.24cm)
Height is 2-1/2 inches (6.35cm)
Depth is 1-1/2 inches (3.81cm)
TM2 and RAA2 Weight
1 pounds (0.4 kg) net, 2 pounds (0.8 kg) in shipping
carton
Shipping Carton Dimensions
Width is 12-1/4 inches (31.12cm)
Depth is 9-1/4 inches (23.5cm)
Height is 5 inches (12.7cm)
Harmonic Distortion
0.25%, 80% Modulation
Selectivity
50dB Adjacent Channel
TM2 - AM Analog Specifications, con’t
