11
How to Connect for Bi-Amp
Cable
Openings
Terminal
Connections
Cover
Cover
Mounting
Screw
Location
Cover
Mounting
Screw
Location
Rear
Chassis
Handle
Figure 7b (Outside USA and Canada)
McIntosh
Loudspeaker
McIntosh Preamplifier
McIntosh
Amplifier
One
McIntosh
Amplifier
Two
Connect to
AC Outlet
Connect to
AC Outlet

Table of Contents

Other manuals for McIntosh MC1.2KW

Preview: Service Manual
Service Manual22 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McIntosh MC1.2KW and is the answer not in the manual?

McIntosh MC1.2KW Specifications

General IconGeneral
Damping factor100
Amplifier class-
Frequency range10 - 100000 Hz
Output impedance8 Ω
Audio output channels1.0 channels
Peak power per channel1200 W
Signal-to-Noise Ratio (SNR)124 dB
Total Harmonic Distortion (THD)0.005 %
Speakers connectivity typeBinding post
PurposePerformance/stage
Product colorBlack, Silver
Connectivity technologyWired
LED indicatorsYes
Weight and Dimensions IconWeight and Dimensions
Depth558.8 mm
Width450.9 mm
Height312.7 mm
Weight66700 g
