McIntosh MC1.2KW User Manual

5
Dimensions
Dimensions
The following dimensions can assist in determining the
best location for your MC1.2KW. There is additional
information on the next page pertaining to installing the
MC1.2KW into cabinets.
17-3/4"
45.09cm
11"
27.94cm
12-5/16"
31.27cm
18"
45.72cm
19-1/2"
49.50cm
3/16"
0.48cm
10-1/2"
26.70cm
14"
35.60cm
1-9/16"
3.96cm
1-1/2"
3.81cm
12-1/4"
31.11cm
17-3/8"
44.15cm
1-5/8"
4.12cm
Front View of the MC1.2KW
Rear View of the MC1.2KW
Side View of the MC1.2KW

McIntosh MC1.2KW Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	10 - 100000 Hz
Output impedance	8 Ω
Audio output channels	1.0 channels
Peak power per channel	1200 W
Signal-to-Noise Ratio (SNR)	124 dB
Total Harmonic Distortion (THD)	0.005 %
Speakers connectivity type	Binding post
Purpose	Performance/stage
Product color	Black, Silver
Connectivity technology	Wired
LED indicators	Yes

Weight and Dimensions

Depth	558.8 mm
Width	450.9 mm
Height	312.7 mm
Weight	66700 g
