McIntosh MC462 User Manual

11
Output Terminals and How to Connect for Bi-Amp
WARNING: Loudspeaker terminals are hazard-
ous live and present a risk of electric
shock. For additional instruction on
making Loudspeaker Connections con-
tact your McIntosh Dealer or McIn-
tosh Technical Support.
15. Attach the Terminal Connections Covers to the
MC462 Rear Panel with the previously removed
Screws. Refer to figure 6.
16. Connect the MC462 power cord to an active AC
outlet.

McIntosh MC462 Specifications

General

Power Output per Channel	450 Watts
Number of Channels	2
Total Harmonic Distortion	0.005%
Frequency Response	20Hz - 20kHz (+0, -0.25dB)
Dynamic Headroom	1.8dB
Damping Factor	>40
Rated Power Band	20Hz - 20kHz
Frequency Response Extended	10Hz - 100kHz (+0, -3dB)
Remote Power Control	Yes
Multi-Channel DB25 Cable	No
Output Impedance	2, 4, 8 Ohms
Dimensions	17.5 x 10.5 x 22 inches (W x H x D)
